Mobile Stone Crusher Plant – Tracked & Wheeled, Go Where the Rock Is, Crush It On-Site Searching for a flexible mobile stone crusher plant for sale that eliminates costly haulage? Our portable stone crusher plant delivers high-capacity, precise grading at a competitive mobile crushing plant price. Quick Specs – Popular Configuration (100-150 tph, Tracked):
advantage Durable and sturdy, with low energy consumption
Get a Quick Quote & Free Consultation →
Our mobile stone crusher plant is the definitive solution for quarrying, mining, and recycling projects that demand both high output and frequent relocation. As a specialist mobile crushing plant manufacturer, we deliver complete, self-propelled or towable portable stone crushing plants built around proven jaw, impact, and cone crushers. Whether configured as a tracked mobile stone crusher plant for rough terrain or a wheeled mobile crusher plant for faster road transport, each system integrates feeding, crushing, screening, and conveying into one coordinated train of machines. This mobile aggregate crushing plant eliminates the need for concrete foundations, fixed steel structures, and dump-truck haulage. Simply drive onto the site, unfold the conveyors, and start producing graded aggregates within 15 minutes. For contractors, quarry operators, and recyclers seeking a truly flexible mobile stone crusher plant for sale, this is the investment that moves with your business and scales to your demands.
The mobile stone crushing plant process is a synchronized multi-machine flow. Raw rock is loaded by an excavator into the hopper of the tracked mobile jaw crusher, which performs primary reduction. The crushed material is then transferred via the jaw unit's side conveyor to the feed hopper of the tracked mobile impact crusher (or cone crusher for hard rock), where it undergoes secondary crushing and shaping. From there, the material is conveyed to the mobile vibrating screen, which separates it into 2-4 clean final product piles. Oversized material is recirculated back to the secondary crusher via a return conveyor. This entire how a mobile stone crusher plant works sequence runs without any fixed infrastructure—the machines are positioned close together, linked by their on-board conveyors, and controlled wirelessly or via a single control panel. At the end of the shift, they can be moved to a new face or loaded onto trailers for the next site.
This versatile mobile stone crusher plant thrives wherever on-site crushing delivers a competitive advantage. It’s the ideal portable rock crushing plant for:
Quarrying: Primary and secondary crushing of granite, basalt, limestone, and dolomite into concrete aggregates
Road & Infrastructure Construction: Producing road base, sub-base, and asphalt aggregates directly along the alignment
Mining Overburden & Ore: Crushing copper, gold, and iron ores close to the pit, reducing haulage costs
Urban Construction & Demolition: A mobile concrete crushing plant that turns demolition waste into recycled aggregates on tight city sites
Temporary & Remote Projects: Dam construction, wind farms, and pipeline projects requiring a temporary aggregate supply
Whether you need a mobile jaw and impact crusher plant for limestone or a mobile jaw and cone crusher plant for hard granite, the combination can be perfectly matched to your rock type and product specification.
Highway Project, Australia: A 150 tph tracked mobile stone crusher plant (Jaw + Impact + Screen) follows a 350 km highway construction project. Set up in under 30 minutes at each new location, it produced 300,000 tonnes of road base from local quarried rock, saving an estimated AUD 2.5 million in trucking. “The mobile crushing plant price was recovered within the first 18 months of the contract.”
Granite Quarry, South Africa: A 200 tph mobile jaw and cone crusher plant crushes hard granite on multiple benches. The tracked units climb the quarry ramp daily, eliminating dump trucks and reducing fuel costs by 60%.
Urban Demolition, Germany: A compact mobile concrete crushing plant processes brick and concrete debris on a tight city-center plot, meeting strict noise and dust regulations while producing recycled aggregate for the new building’s base course.
Join the growing number of operators who have made the move to mobile stone crushing.
Installation of a mobile stone crusher plant is as simple as positioning the units on level ground. Our commissioning engineers travel to your site to oversee the positioning, calibrate the wireless interlocking, and train your operators on safe and efficient mobile production. We maintain regional stocks of critical mobile crusher plant parts—jaw plates, blow bars, cone mantles, screen meshes, track pads, and engine kits—available for dispatch within 48 hours. With our service agreements, your mobile aggregate crushing plant will continue delivering top-tier performance wherever your projects take you.
Pre-configured mobile stone crusher plants, adaptable to rock type and product requirements.
| Plant Scale | Capacity (tph) | Primary Unit | Secondary Unit | Screening Unit | Total Power (kW) | Transport Units |
|---|---|---|---|---|---|---|
| MP-50 (Small) | 30-50 | MPJ-400 Tracked Jaw | MPI-1007 Tracked Impact | MPS-1545 Tracked Screen | ~150 | 3 trailers / self-move |
| MP-100 (Medium) | 80-120 | MPJ-600 Tracked Jaw | MPI-1214 Tracked Impact / MPC-1200 Tracked Cone | MPS-2160 Tracked Screen | ~300 | 3 trailers / self-move |
| MP-150 (Large) | 120-180 | MPJ-750 Tracked Jaw | MPI-1315 Tracked Impact / MPC-1750 Tracked Cone | MPS-2470 Tracked Screen | ~500 | 3 trailers / self-move |
| MP-250 (XL) | 200-300 | MPJ-900 Tracked Jaw | MPI-1520 Tracked Impact / MPC-2200 Tracked Cone | MPS-3060 Tracked Screen | ~750 | 3-4 trailers / self-move |
| MP-500 (Mega) | 350-500 | MPJ-1200 Tracked Jaw | 2×MPI-1315 Tracked Impact | 2×MPS-2470 Tracked Screen | ~1100 | 5-6 trailers / self-move |
All mobile stone crusher plants for sale can be configured with wheeled chassis, dual-power, and additional recycling options like magnetic separators. Contact us for a custom configuration.
